Belle PCLX 40E+ Battery Powered Plate Compactor (Whacker Plate)

Belle PCLX 40E+ Battery Powered Plate Compactor

The Belle PCLX 40E+ is an 82V battery powered forward plate compactor with a 400mm plate, driven by a 1.5kW brushless motor and supplied with an 8Ah battery and charger. It produces 13kN of centrifugal force at 101Hz with a maximum travel speed of 20m per minute, and the battery is interchangeable across the Belle E+ 82V range.

Running on battery rather than petrol removes exhaust emissions at the point of work, and hand-arm vibration is held below 2.5m/s2. Used for compacting in basements, tunnels and poorly ventilated areas and for work in emission controlled and environmentally sensitive locations where emission-free compaction is required.

Specifications

Type: Forward plate compactor
Plate Width: 400mm
Centrifugal Force: 13kN
Frequency: 101Hz
Motor: 1.5kW brushless
Battery: 82V 8Ah, charger supplied
Max Travel Speed: 20m per minute
Max Gradient: 20 degrees
Static Pressure: 337kg per square metre
Hand-arm Vibration: Below 2.5m/s2
Operating Size: 1060mm long x 910mm high
Storage Size: 780mm long x 500mm high
Weight: 65.9kg with battery and charger

Key Features

• 400mm compaction plate
• 13kN centrifugal force at 101Hz
• 1.5kW brushless motor
• 82V 8Ah battery and charger supplied
• Battery interchangeable across the E+ 82V range
• No exhaust emissions at the point of work
• Hand-arm vibration below 2.5m/s2
• Folds to 780 x 500mm for storage
• Optional water kit and paving pad available
